High capacity levelwind motorized hose reel
Organize and handle bulky hose with ease
Smooth and low-effort hose extention
Our patented “Zero-Effort” drive motor as well as high quality buttery-smooth pillow-style bearings allow for ease of extension. Just grab and go at the worksite!
Fast and easy hose retreival
Retract with the push of a button. Model LW Max uses a high speed motor that rewinds at over 2.5ft/second. Save your back with no more cumbersome cranking and save valuable time during end of job breakdown.
Customize retraction tension for your hose
The integrated tension control mechanism ensures you can dial in the amount of rewind inertia based upon the size and weight of your hose.
Save valuable space with compact storage and stackable design
Our integrated levelwind mechanism minimises space required. The sturdy frame is designed to be stackable which allows you to keep lost space to a miminum.
Take your setup to the next level with our optional wireless remote
The simple addition of our wireless remote turns long bulky hose retrieval into a one-person job. One remote can contorol up to 4 units to give you master control from anywhere.
Lock the hub and protect your assets
Robust anti-theft locking latch keeps your valuable hose from “opportunists”.
| PRESSURE RATING | 4500psig working pressure |
| INLET THREAD SIZE | 1/2″ NPT |
| OUTLET THREAD SIZE | 3/8″ OR 1/2″ NPT |
| HOSE OD RANGE | 0.625″ – 1.125″ |
| BEARINGS | Pillow-Block Style |
| HOSE LENGTH CAPACITY | ø 1.125″: 150′ ø 1.000″: 200′ ø 0.750″: 325′ ø 0.625″: 500′ |
| CONSTRUCTION | Anodized aluminum frame with stainless steel torx drive fasteners |
| DRIVE MOTOR | 12 or 24 VDC |
